Technical Parameters |
|
|
Item |
VHF-LISNBM3-16 |
|
Standard |
CISPR16-1-4 Ed.3.2 |
|
Frequency Range |
30 MHz-300 MHz |
|
Max. AC Voltage（L-PE） |
250 V |
|
Max. DC Voltage（L-PE） |
400 V |
|
Max. Current |
16 A |
|
Type of EUT Port |
|
|
Type of AE Port |
4 mm Banana(L/N/PE) |
|
Input Impedance（ EUT End, L line-Reference Ground, N line-Reference Ground） |
|
|
30MHz to 300MHz |
50 Ω ± 20% |
|
Phase（EUT End, L line, N line） |
|
|
30MHz to 108MHz |
0 ± 11.5° |
|
108MHz to 300MHz |
0 ± 25.0° |
|
Isolation(AE-EUT) |
|
|
30MHz to 300MHz |
>40 dB |
|
General Parameters |
|
|
Dimension |
250 mm (L) ×160 mm (W) ×100 mm（H） |
|
Weight |
4.0 kg |
|
Ambient Temperature |
15–35℃ |
|
Relative Humidity |
45%–75% |
|
Atmosphere Press Range |
86 kPa–106 kPa |
|
Accessories Supplied with Product |
|
Operating Manual, Factory Test Report, Test cables, Fuse and Quality Guarantee. |
