Technical Parameter

Unit type

TPS-CS106

TPS-CS106(1000V)

Test voltage range

0 ~ 600 V
(Continuously adjustable)

0.15 μs ：0 ~ 600 V
(Continuously adjustable)

5 μs/10 μs ：0 ~ 1000 V
(Continuously adjustable)

Calibration voltage

100 V ~ 600 V， ±10%

0.15 μs ：100 V ~ 600 V， ±10%

5 μs/10 μs ：100 V ~ 1000 V， ±10%

GJB 151A-1997
GJB 152A-1997
Waveform parameters and impedance

0.15 μs pulse (50% ~ 0%)

≤0.15 μs  (＜5 ohm)

5 μs pulse (50% ~ 0%)

≤5 μs  (＜2 ohm)

10 μs pulse (50% ~ 0%)

≤10 μs  (＜1 ohm)

GJB 151B-2013
MIL-STD-461F
Waveform parameters and impedance

Rise time

1.5 μs±0.3 μs

Fall time

3.5 μs±0.3 μs

Duration time

5.0 μs（±22%）

Sag or undershoot amplitude

≤30% Vp

Sag or undershoot time

＜20 μs

Source impedance

≤2 Ω

Output Polarity

+/- (only positive for 0.15 μs)

Trigger

External, automatic and manual

Pulse repetition frequency

Standard configuration 1~20 pps

Customizable configuration:

1~50 pps (0.15 μs)

1~100pps (5 μs & 10 μs)

External Phase Sync

0°~360°, mains frequency   50 Hz~1000 Hz,    available for async

Parallel Connection

Built-in coupler

Series Connection

5 μs/10 μs coupler external (32 A, 50 A, 100 A, 200 A, 300 A optional, higher current can be customized); 0.15 mu s coupler built-in (32 A, 50 A);

0.15 mu s coupler external (100 A, 200 A, 300 A optional, higher current can be customized)

Output Ports

4 mm plugs

Calibration Resistance

External

General parameters

Display Screen

5.7” TFT touch screen

Power Supply

AC 220 V 50 Hz

Fuse

6A

Max. Power Consumption

200 W

Dimension

19”/4U

Weight

Approx.20 kg

Ambient Temperature

15 ℃~35 ℃

Relative Humidity

45% - 75%

Atmospheric Pressure

86 kPa – 106 kPa

Standard accessories

User manual, Testing line, Power line, Earth line, Fuses，Calibration resistor CRM 050

1、Calibration resistance module CRM 050

Non-inductive resistance： 5 Ω
Dimension：60*65*30 mm (L*W*H)
Weight：0.1 kg

Optional accessories

600V System configuration:

1、Microsecond pulse transformer TPT-600-5

For coupling 5 μs, 10 μs waveform, Max Coupling pulse voltage： 600 V
Max. secondary side current load：300 A
Dimension：250*185*400 mm(W*H*D)
Weight：15.5 kg

2、0.15 μs waveform module TPS-CS106-1

For coupling 0.15 μs waveform, Max Coupling pulse voltage： 600 V
Max. secondary side current load：300 A
Dimension：250*185*400 mm(W*H*D)
Weight：6.5 kg

1000V System configuration:

3、Microsecond pulse transformer TPT-1000-1

For coupling 5 μs, 10 μs waveform, Max Coupling pulse voltage： 1000 V
Max. secondary side current load：300 A
Dimension：250*185*400 mm(W*H*D)
Weight：15.5 kg

4、0.15 μs waveform module TPS-CS106-100

For coupling 0.15 μs waveform, Max Coupling pulse voltage： 600 V
Max. secondary side current load：300 A
Dimension：250*185*400 mm(W*H*D)
Weight：6.5 kg

5、Microsecond pulse transformer TPT-600-4

For coupling 5 μs, 10 μs waveform,
Max Coupling pulse voltage： 600 V
Max. secondary side current load：50 A
Dimension：185*140*45 mm(L*W*H)
Weight：5 kg

6、Feed-through capacitor DCM 4032

Voltage：500 V AC
Current：32 A
Capacitor：10 μF
Dimension：225 *100 *100 mm (L*W*H)
Weight：2.5 kg

7、 Feed-through capacitor DCM 4050

Voltage：500 V AC
Current：50 A
Capacitor：10 μF
Dimension：225 *100 *100 mm(L*W*H)
Weight：2.5 kg

8、Feed-through capacitor DCM 40100

Voltage：500 V AC
Current：100 A
Capacitor：10 μF
Dimension：225 *100 *100 mm(L*W*H)
Weight：2.5 kg

9、Artificial mains network LISN J50

Inductance：50 μH；
Through-current capability：50 A
Dimension：160 *170 *410 mm(L*W*H)
Weight：3 kg
