The PPS 45C10 programmable AC/DC power source features high voltage/current dynamic range and is well suited for testing in aviation sector.
CPN 38100T30High voltage and high power impulse current coupling/decoupling network, coupled with host S15C3000 for 8/20μs current waveform test, coupled pulse current up to 30 kA.
S5D60 is a new type of impulse current simulator developed according to the requirements of IEC 61643-11 and GB/T 18802.11 standards. It can output 10/1000 μs pulse current waveform with a maximum output current of 600 A.
S5C800 is a new type of impulse current simulator developed according to the requirements of IEC 61643-11 and GB/T 18802.11 standards. It can output 8/20 μs pulse current waveform with a maximum output current of 8 kA.
The EDS MAX20 is 3CTEST’s fourth - generation electrostatic discharge simulator in compliance with IEC 61000 - 4 - 2 and other standards.
The EDS MAX16 is 3CTEST’s fourth - generation electrostatic discharge simulator in compliance with IEC 61000 - 4 - 2 and other standards.
The INR 60 Inductive Noise Immunity Tester is developed according to the Toyota TSC0502G Fig.22 standard. It simulates the high-voltage noise waveform generated in a vehicle...
The CN 416M5-100 coupling network is suitable for (common mode conducted immunity) 5-wire cables, and its coupled common mode conducted immunity voltage can reach 300V.
CDN 405M40-32 is suitable for coupling and decoupling testing networks of data and control lines for 4 unshielded asymmetric lines during surge testing, with a peak voltage of up to 6 kV.
The BCM 0220M surface current probe is used for measuring the induced current on the surface of conductors in electromagnetic radiation environments.
